References Overhead scrap crane 2 x 55 t + 10 t - 27 m - Královopolská Brno

Detail information

The scrap crane is designed for handling and transporting scrap baskets from wagons to a scrap wagon for filling a steelmaking furnace. This crane replaces an obsolete crane.

The new crane is designed with a more powerful and durable construction as a double girder with a main trolley 2 x 55 t for the transport of scrap baskets and an auxiliary cantilever trolley 10 t for auxiliary operations.

Specification

  • Weight: 230 t
  • Load capacity of main lift: 2 x 55 000 kg
  • Auxiliary lift load capacity: 10 000 kg
  • Lifting capacity of the chain block: 5 000 t
  • Span: 27 000 mm

  • Classification: ISO 4301-5, A8
  • Parameters: This overhead crane is designed as a double-girder crane with the trolley.
  • Material main steel structure: EN10113, 1.0546-S355J2+N
  • Auxiliary steel structure: EN10025, S355J2G3, S235J2G3
  • Crane wheels: DIN17200, 42CrMo4

Customer

  • Customer: TŘINECKÉ ŽELEZÁRNY, a. s..
  • Place: Trinec
  • Region: Czechia
  • Year: 2020
